Metalized Bopp Splicing & Seaming Tape

Sizes Available: 48mm x 110m -- 24 rolls/case 72mm x 110m -- 24 rolls/case

Description

This tape is made of a special UV Metalized Treated Polypropylene (BOPP) film and coated with high shear, high tack solvent acrylic adhesive. Its temperature resistance makes it ideal for seaming heat repellent radiant foils.

Benefits of the Metalized Bopp Splicing & Seaming Tape

  • Excellent alternative to aluminum foil tape. No liner makes it easier and faster to use and delivers a tighter seal due to the elongation characteristic of the film
  • High shear, high tack solvent acrylic adhesive
  • Meets ULC-S109-2003-Standard for flame test on flame resistance fabrics and films as required by National Building Code 9.33.6.3
  • Strong holding power provides permanent bond
  • Resistant to mold, moisture, flame spread and smoke generation
  • UV resistant
  • Can be torn by hand
  • Radiant guard

Applications

  • Seaming overlap splice of radiant reflective foil bubble insulation in heated floors or metal buildings
  • Seaming foil water heater jacket
  • Seaming foil covered EPS-backed insulation between wood walls and masonry
  • Splicing of foil water pipe wrap
  • Splicing of foil radiant barrier in an attic
  • Splicing or sealing of fool foil wraps
  • Splicing of foils, papers, and films in the printing, converting and manufacturing process

Downloads

Brochure (EN)

Data Sheet for Metalized Bopp Splicing & Seaming Tape

  • Colour Silver (21)
  • Backing UV Metalized Treated Polypropylene (BOPP) Film
  • Adhesive High Performance Acrylic
  • Thickness 3.0 mils
  • Adhesion 40 oz./in
  • Tensile strength 30 lbs/in
  • Elongation 140%
  • Application Temperature -10°C (14°F) to 50°C (122°F)
  • Temperature Resistance -40°C (-40°F) to 140°C (280°F)
